The MS21922-6 sleeve is a specialized component designed to provide insulation and protection for electrical and mechanical assemblies. It is commonly used in aerospace, military, and industrial applications where reliable insulation and environmental resistance are critical. This sleeve ensures enhanced durability and safety in demanding operational conditions.This component is manufactured to the applicable MS, AN, or NAS specification, ensuring compliance with recognized military and aerospace dimensional, material, and performance requirements. Material certifications, Certificates of Conformance (CoC), and traceability are available where applicable.
hide-Asset:
3011P
hide-Quantity Increment:
1
note-Sold In:
Per Package
note-Units Per Package:
1
spec-Material:
Steel
note-Note:
Our inventory is extensive. The majority of the items listed in our catalog are stocked and available for immediate shipment.
hide-ItemID:
56234
spec-Features:
Flareless
note-Industry Standards/Certification:
MS21922
spec-Dimension G:
0.435"
spec-Dimension H:
0.484"
spec-Dimension A:
0.66"
spec-Dimension D:
0.419"
spec-Dimension A Tolerance:
0.01"
spec-Dimension E:
0.38"
spec-Tube Outside Diameter:
3/8"
spec-Dimension E Tolerance:
-0.000|+0.003"
spec-Dimension G Tolerance:
-0.000|+0.004"
spec-Alternate Part Number:
Possible
spec-NSN:
4730-00-554-7398
spec-NIIN:
00-554-7398
hide-Part # Unpunctuated:
MS219226
note-Minimum Order Note:
Minimum order is 1. Must order in increments of 1.
