The Hi-Lok HL40-4-5 is a high-strength fastener designed for critical aerospace and industrial applications requiring reliable, vibration-resistant connections. It is commonly used in aircraft structural assemblies, engine components, and other high-performance engineering environments. Its precision-engineered design ensures secure fastening under demanding operational conditions, enhancing safety and durability.
hide-Asset:
2796P
hide-Quantity Increment:
1
note-Sold In:
EA
note-Units Per Package:
1
spec-Material:
A-286 High Temperature Alloy
note-Note:
Our inventory is extensive. The majority of the items listed in our catalog are stocked and available for immediate shipment.
hide-ItemID:
60079
spec-Thread Size:
#6-32
spec-Head Type:
Protruding Shear
spec-Maximum Grip:
5/16"
spec-Nominal Diameter:
1/8"
spec-Diameter A:
0.225|0.240"
spec-Reference B:
0.294"
spec-Diameter TD:
0.1310|0.1335"
spec-Reference G:
0.02"
spec-Dimension H:
0.032|0.042"
spec-Minimum Double Shear Load:
2840 lb
spec-Minimum Tension Load:
1350 lb
spec-Diameter D with Coating or Solid Film Lubricant:
0.1365|0.1375"
spec-Diameter D without Coating or Solid Film Lubricant:
0.1370|0.1375"
spec-Maximum Grip + B Tolerance:
±0.010"
spec-Maximum Grip Tolerance:
±0.005"
spec-Manufacturer:
Hi-Lok
spec-NSN:
5320-01-482-8134
spec-NIIN:
01-482-8134
hide-Part # Unpunctuated:
HL4045
note-Minimum Order Note:
Minimum order is 10. Must order in increments of 1.
