The Bleeder Plug - S/S - AN814-6J is a stainless steel fitting designed for bleeding air or fluids from hydraulic and pneumatic systems. It is commonly used in aerospace, automotive, and industrial applications to ensure system integrity and prevent pressure buildup. Its durable construction provides reliable performance in high-pressure environments, facilitating maintenance and system efficiency.This component is manufactured to the applicable MS, AN, or NAS specification, ensuring compliance with recognized military and aerospace dimensional, material, and performance requirements. Material certifications, Certificates of Conformance (CoC), and traceability are available where applicable.
hide-Asset:
2635P
hide-Quantity Increment:
1
note-Sold In:
Per Package
note-Units Per Package:
1
spec-Material:
Corrosion Resistant Steel
note-Note:
Our inventory is extensive. The majority of the items listed in our catalog are stocked and available for immediate shipment.
hide-ItemID:
55435
spec-Features:
Screw Thread
note-Industry Standards/Certification:
AN814
spec-Dimension L:
9/16"
spec-Diameter B:
15/32"
spec-Dimension D:
23/32"
spec-Dimension E:
0.813"
spec-Tube Outside Diameter:
3/8"
spec-Thread Size (Reference):
9/16"-18
spec-Dimension E Tolerance:
0.004"
spec-Diameter F:
0.482"
spec-Dimension K:
27/64"
spec-Chamfer Angle:
45 º
spec-Diameter F Tolerance:
-0.003|+0.002"
spec-NSN:
5365-00-248-3198
spec-NIIN:
00-248-3198
hide-Part # Unpunctuated:
AN8146J
note-Minimum Order Note:
Minimum order is 1. Must order in increments of 1.
note-Inventory Note:
Need additional stock? Call (877) 920-1876 or email
note-California Residents:
Prop 65 Warning: This product may contain chemicals known to the State of California to cause cancer, and birth defects or other reproductive harm.
